Creating artistic images from Strava rides

When you upload a ride, Strava draws a map using the longitude and latitude coordinates recorded by your GPS device. This article explores ways in which these numbers, along with other metrics, can be used to create interesting images that might have some artistic merit.

The idea was motivated by the huge advances made in the field of Deep Learning, particularly applications for image recognition. However, since datasets come in all shapes and forms, researchers have explored ways of converting different types of data into images. In a paper published in 2015, the authors achieved success in identifying standard time series by converting them into images.

GPS bike computers typically record snapshots of information every second. What kind of images could these time series generate? It turns out that there are several ways to convert a time series into an image.

Spectrogram

Creating a spectrogram is a standard approach from signal processing that is particularly useful for analysing acoustic files. The spectrogram is a heat map that shows how the underlying frequencies contributing to the signal change over time. Technically, it is derived by calculating the discrete Fourier transform of a window that slides across the time series. I applied this to my regular Saturday morning club ride of four laps around Richmond Park. The image changes a bit once the ride gets going after about 1200 seconds (20 minutes), but, frankly, the result was not particularly illuminating. There is no obvious reason to consider cycling power data as a superposition of frequencies.

spectrogram

Ah! Now we are getting somewhere

The authors of the referenced paper took a different approach to produce things called Gramian Angular Summation Field (GASF), Gramian Angular Difference Field (GADF), and Markov Transition Field (MTF). Read the paper if want to know the details. I created these and something call a Recurrence Plot. All of these methods generate a matrix, by combining every element in the time series with every other element. The underling observations occurring at times $t_{1}$ and $t_{2}$ determine the colour of the pixel at position ( $t_{1}$ , $t_{2}$ ). Images are symmetric along the lower-left to upper-right diagonal, apart from GADF, which is antisymmetric.

Let’s see how do they look for on four laps of Richmond Park. We have six time series, with corresponding sets of images below. The segmentation of the images is due to periodicity of the data. This is particularly clear in the geographic data (longitude, latitude and altitude). The higher intensity of the main part of the ride is most obvious in the heart rate data. The MTF plots are quite interesting. Scroll down through the images to the next section

data1 — Raw time series of power, heart rate, cadence, longitude, latitude and altitude

From cycle ride to art

It is one thing to create an image of each item, but how can we combine these to summarise a ride in a single image. I considered two methods of combining time series into a single image: a) create a new image where the vertical and horizontal axes represent different series and b) create a new image by simply adding the corresponding values from two underlying images.

One problem is that some cyclists don’t have gadgets like heart rate monitors and power meters, so I initially restricted myself to just the longitude, latitude and altitude data. Nevertheless, as noted in an earlier blog, it is possible to work out speed, because the time interval is one second between each reading. Furthermore, one can estimate power, from the speed and changes in elevation.

Another problem is that rides differ in length. For this I split the ride into, say, 128 intervals and took the last observation in each interval. So for a 3 hour ride, I’d be sampling about once every 84 seconds.

The chart at the top of this blog was created by first normalising each series to a standard range (-1, +1). Method a) was used to create two images: longitude was added to latitude and altitude was multiplied by speed. These were added using method b). Using these measures will produce pretty much the same chart each time the ride is done. In contrast, an image that is totally unique to the ride can be produced using data relating to the individual rider. The image below uses the same recipe to combine speed, heart rate, power and cadence. If this had been a particularly special ride, the image would be a nice personal memento.

lastimage — A different take on four laps of Richmond Park

For anyone interested in the underlying code, I have posted a Jupyter notebook here.

References

Encoding Time Series as Images for Visual Inspection and Classification Using Tiled Convolutional Neural Networks, Wang Z Oates T, https://www.aaai.org/ocs/index.php/WS/AAAIW15/paper/viewFile/10179/10251

Strava – Automatic Lap Detection

Screen Shot 2018-08-04 at 16.30.58 — Opening Laps of Hillingdon Race

As you upload your data, you accumulate a growing history of rides. It is helpful to find ways of classifying different types of activities. Races and training sessions often include laps that are repeated during the ride. Many GPS units can automatically record laps as you pass the point where you began your ride or last pressed the lap button. However, if the laps were not recorded on the device, it is tricky to recover them. This article investigates how to detect laps automatically.

First consider the simple example of a 24 lap race around the Hillingdon cycle circuit. Plotting the GPS longitude and latitude against time displays repeating patterns. It is even possible to see the “omega curve” in the longitude trace. So it should be possible to design an algorithm that uses this periodicity to calculate the number of laps.

Screen Shot 2018-08-03 at 19.07.16 This is a common problem in signal processing, where the Fourier Transform offers a neat solution. This effectively compares the signal against all possible frequencies and returns values with the best fit in the form of a power spectrum. In this case, the frequencies correspond to the number of laps completed during the race. In the bar chart below, the power spectrum for latitude shows a peak around 24. The high value at 25 probably shows up because I stopped my Garmin slightly after the finish line. A “harmonic” also shows up at 49 “half laps”. Focussing on the peak value, it is possible to reconstruct the signal using a frequency of 24, with all others filtered out.

Screen Shot 2018-08-03 at 19.20.38

So we’re done – we can use a Fourier Transform to count the laps! Well not quite. The problem is that races and training sessions do not necessarily start and end at exactly the starting point of a lap. As a second example, consider my regular Saturday morning club run, where I ride from home to the meeting point at the centre of Richmond Park, then complete four laps before returning home. As show in the chart below, a simple Fourier Transform approach suggests that ride covered 5 laps, because, by chance, the combined time for me to ride south to the park and north back home almost exactly matches the time to complete a lap of the park. Visually it is clear that the repeating pattern only holds for four laps.

Screen Shot 2018-08-03 at 19.35.07

Although it seems obvious where the repeating pattern begins and ends, the challenge is to improve the algorithm to find this automatically. A brute force method would compare every GPS location with every other location on the ride, which would involve about 17 million comparisons for this ride, then you would need to exclude the points closely before or after each recording, depending on the speed of the rider. Furthermore, the distance between two GPS points involves a complex formula called the haversine rule that accounts for the curvature of the Earth.

Fortunately, two tricks can make the calculation more tractable. Firstly, the peak in the power spectrum indicates roughly how far ahead of the current time point to look for a location potentially close to the current position. Given a generous margin of, say, 15% variation in lap times, this reduces the number of comparisons by a whole order of magnitude. Secondly, since we are looking for points that are very close together, we only need to multiply the longitudes by the cosine of the latitude (because lines of longitude meet at the poles) and then a simple Euclidian sum the squares of the differences locates points within a desired proximity of, say, 10 metres. This provides a quicker way to determine the points where the rider was “lapping”. These are shaded in yellow in the upper chart and shown in red on a long/latitude plot below. The orange line on the upper chart shows, on the right hand scale, the rolling lap time, i.e. the number of seconds to return to each point on the lap, from which the average speed can be derived.

Screen Shot 2018-08-03 at 20.26.18

Two further refinements were required to make the algorithm more robust. One might ask whether it makes a difference using latitude or longitude. If the lap involved riding back and forth along a road that runs due East-West, the laps would show up on longitude but not latitude. This can be solved by using a 2-dimensional Fourier Transform and checking both dimensions. This, in turn, leads to the second refinement, exemplified by the final example of doing 12 ascents of the Nightingale Lane climb. The longitude plot includes the ride out to the West, 12 reps and the Easterly ride back home.

Screen Shot 2018-08-03 at 20.34.02

The problem here was that the variation in longitude/latitude on the climb was tiny compared with the overall ride. Once again, the repeating section is obvious to the human eye, but more difficult to unpick from its relatively low peak in the power spectrum. A final trick was required: to consider the amplitude of each frequency in decreasing order of power and look out for any higher frequency peaks that appear early on the list. This successfully identified the relevant part of the ride, while avoiding spurious observations for rides that did not include laps.

The ability for an algorithm to tag rides if they include laps is helpful for classifying different types of sessions. Automatically marking the laps would allow riders and coaches to compare laps against each other over a training session or a race. A potential AI-powered robo-coach could say “Ah, I see you did 12 repeats in your session today… and apart from laps 9 and 10, you were getting progressively slower….”

Surrey Cycle Racing League Courses

Cyclists in southeast England are indebted to Glyn Durrant, who with his team of supporters and local club members, runs the Surrey Cycle Racing League. These very popular races are held throughout the year on a number of courses around the region. This article takes a look at the characteristics of the courses raced in the Surrey League.

Thanks to Russell Short, Surrey League course are available as routes on Strava. I have created a map that displays all thirty-one circuits. You can view it, if you go to the trouble of opening to this page, then you have to press on the download icon and open the file in your browser. If you hover over the marker on each course, it indicates the usual finish line and the name of the course. The different colours help identify where loops pass over the same roads.

The courses have a range of characteristics, each one suiting some riders better than others. Although they are all road races, shorter circuits like the 4.6km lap around Kitsmead Lane are repeated many times, giving more of a criterion feel, in contrast with longer routes like the 24.1km Lingfield loop that offer less opportunity to memorise the finishing straight.

The amount of climbing is a key feature. For example, the Newchapel course is almost pan flat, whereas Beachy Head has an elevation gain of 228m over a length of 11.7km. Since you end up at the same point on each loop, we can assume that you are climbing for about half of the distance, giving an average climb (and descent) of 3.9%.

The organisers tend to position the chequered flag at the top of a rise, but the final effort required on Milland Hill is far greater than, say, Seale, which is slightly downhill for the indicated finish line. The rider leading the last Milland Hill climb will tend to be someone who can generate a high level of power at the end of the race. In order to identify steep finishes, the gradient of the final kilometre is calculated using the finish line as it appears in the Strava route. This is not 100% reliable, because the actual finish line can be different on the day.

Some courses are more technical than others, involving twists, turns and sharp corners. These favour riders with good bike-handling skills. One way to assess this is to calculate the “fractal dimension” of the route. This method is a bit experimental, so it would be interesting to receive comments from riders on whether they agree with the ranking. The metric gives a figure close to one for smooth, straight courses, but higher numbers for twisty circuits. None of the routes is very technical, but Sharpethorne and South Nutfield score more highly, due to some very sharp turns.

Putting all this together leads to some interesting results. Consider the amount of climbing versus the length of each circuit. Beachy Head is a medium length route that is well suited to climbers, though heavier riders have a chance to catch up on the fast descent. Sharpethorne, Staplefield and Lingfield are long and hilly, whereas you have less time to recover from the climbs at Ladies Mile, Staple Lane and Seale, because they are much shorter. Meanwhile Milland Hill and Bletchingly form part of a medium-length hilly group, contrasting with the Laughton, Coolham, Kirdford group of flatter courses. The very flat Newchapel course should suit the heavier diesel-powered TTers.

Taking account of the technical nature of the courses, Newchapel, Sharpethorne and Beachy Head form a triangle of extremes. The flat non-technical Newchapel course can be ridden at a very high average speed. Sharpethorne requires both climbing ability and good bike handling skills. Beachy Head is hilly but not too technical. Most of the other routes are intermediates.

The hilliest course does not necessarily have the steepest finish. That honour is reserved for the brutal climb that concludes Milland Hill, though the Bletchingly finish is also tough. Note once again that this depends on where the finish line is positioned on the day – I’m sure the finish of Beachy Head was at the summit, last time I did it!

The Surrey League offers a range of courses that provide opportunities for different types of riders. None of them is super-technical. Unfortunately we don’t have any mountains so strong puncheurs tend to do well. Remember that it is well worth reminding yourself what type of course you are riding, before you start the race. Please take a look at the spreadsheet summary of the data with useful links available here: SurreyLeagueRoutes

The fractal nature of GPS routes

The mathematician, Benoît Mandelbrot, once asked “How long is the coast of Britain?“. Paradoxically, the answer depends on the length of your measuring stick. Using a shorter ruler results in a longer total distance, because you take account of more minor details of the shape of the coastline. Extrapolating this idea, reducing the measurement scale down to take account of every grain of sand, the total length of the coast increases without limit.

This has an unexpected connection with the data recorded on a GPS unit. Cycle computers typically record position every second. When riding at 36km/h, a record is stored every 10 metres, but at a speed of 18k/h, a recording is made every 5 metres. So riding as a lower speed equates to measuring distances with a shorter ruler. When distance is calculated by triangulating between GPS locations, your riding speed affects the result, particularly when you are going around a sharp corner.

Consider two cyclists riding round a sharp 90-degree bend with a radius of 13m. The arc has a length of 20m, so the GPS has time to make four recordings for the a rider doing 18km/h, but only two recordings for the rider doing 36km/h. The diagram below shows that the faster rider will have a record of position at each red dot, while the slower rider also has a reading for each green dot. Although the red and green distances match on the straight section, when it comes to the corner the total length of the red line segments is less than the total of the green segments. You can see this jagged effect if you zoom into a corner on the Strava map of your course. Both triangulated distances are shorter than the actual arc ridden.

It is relatively straightforward to show that the triangulation method will underestimate both distance and speed by a factor of 2r/s*sin(s/2r), where r is the radius of the corner in metres and s is speed in m/s. So the estimated length of the 20m arc for the fast rider is 19.4m ridden at a speed of 35.1km/h (2.5% underestimate), while the corresponding figures for the slower rider would be 19.8m at 17.9km/h (0.6% underestimate).

We might ask whether these underestimates are significant, given the error in locating real-time positions using GPS. Over the length of a ride, we should expect GPS errors to average out to approximately zero in all directions. However, triangulation underestimates distance on every corner, so these negative errors accumulate over the ride. Note that when the bike is stationary, any noise in the GPS position adds to the total distance calculated by triangulation. But guess what? This can only happen when you are not moving fast. The case remains that slower riders will show a longer total distance than faster riders.

The simple triangulation method described above does not take account of changes of elevation. This has a relatively small effect, except on the steepest gradients, thus a 10% climb increases in distance by only 0.5%. In fact, the only reliable way to measure distance that accounts for corners and changes in altitude is to use a correctly-calibrated wheel-based device. Garmin’s GSC-10 speed and cadence monitor tracks the passage of magnets on the wheel and cranks, transmitting to the head unit via ANT+. This gives an accurate measure of ground speed, as long as the correct wheel size is used (and, of course, that changes with the type of tyre, air pressure, rider weight etc.).

According to Strava Support, Garmin uses a hierarchy for determining distance. If you have a PowerTap hub, its distance calculation takes precedence. Next, if you have a GSC-10, its figure is used. Otherwise the GPS positions are used for triangulation. This means that, if you don’t have a PowerTap or a GSC-10 speed/cadence meter, your distance (and speed) measurements will be subject to the distortions described above.

But does this really matter? Well it depends on how “wiggly” a route you are riding. This can be estimated using Richardson’s method. The idea is that you measure the route using different sized rulers and see how much the total distance changes. The rate of change determines the fractal dimension, which we can take as the “wiggliness” of the route.

One way of approximating this method from your GPS data is, firstly, to add up all the distances between consecutive GPS positions, triangulating latitude and longitude. Then do the same using every other position. Then every fourth position, doubling the gap each time. If you happened to be riding at a constant 36km/h, this equates to measuring distance using a 10m ruler, then a 20m ruler, then a 40m ruler etc..

Fractal dimension 1.01

Fractal dimension 1.11

Fractal dimension 1.34

Using this approach, the fractal dimension of a simple loop around the Surrey countryside is about 1.01, which is not much higher than a straight line of dimension 1. So, with just a few corners, the GPS triangulation error will be low. The Sella Ronda has a fractal dimension of 1.11, reflecting the fact that alpine roads have to follow the naturally fractal-like mountain landscape. Totally contrived routes can be higher, such as this one, with a fractal dimension of 1.34, making GPS triangulation likely to be pretty inaccurate – if you zoom in, lots of corners are cut.

In conclusion, if you ride fast around a wiggly course, your Garmin will experience non-relativistic length contraction. Having GPS does not make your wheel-based speed/cadence monitor redundant.

If you are interested in the code used for this blog, you can find it here.
